The Right Decision

Choosing which van is the right one for you or your business can be difficult, so we've compiled a guide to all the dimensions, load spaces and weights of our vans to help you make the right decision every time.

Dummy Text Added so that height of this editable component is generated to make it identifiable and editable in touch UI.
  VAN DIMENSIONS   All dimensions in mm Loadspace
Make Model Variant A B C D E F G H Between wheel arches Load Space (m3) Vehicle weight (kg) Max Payload (kg)
FORD TRANSIT 2.2 TDI 85ps 260 SWB 4863 2067 2374 1370 1540 1430 2582 1390 6.55 2600 901
V222
TRANSIT 2.2 TDI 85ps 280 SWB 4863 2067 2374 1370 1540 1430 2582 1390 6.55 2800 1101
V222
TRANSIT 2.2 TDI 115ps 260 SWB 4863 2067 2374 1370 1540 1430 2582 1390 6.55 2600 892
V222
TRANSIT 2.4 TDI 100ps 350 LWB 5680 2599 2374 1896 1540 1985 3399 1390 11.89 3500 1453
V324
TRANSIT 2.4 TDI 115ps 350 LWB 5680 2599 2374 1896 1540 1985 3399 1390 11.89 3500 1438
V324
TRANSIT 2.4 TDI 140ps 350 LWB 5680 2599 2374 1896 1540 1985 3399 1390 11.89 3500 1419
V324
MERCEDES SPRINTER 313 CDI 3.5T LWB 6940 2705 2426 1940 ? 1780 1940 4300 1350 14 3500 1235
  V421
RENAULT KANGOO 1.5 ML 19 DCI 70 4213 1805 1829 1130 1731 1251 1731 1218 2.3
V115
KANGOO 1.5 ML 19 DCI 85 EXTRA 4213 1805 1829 1130 1731 1251 1731 1218 3
V115
KANGOO 1.5 ML 19 DCI 70 EXTRA 4213 1805 1829 1130 1731 1251 1731 1218 3
V115
KANGOO 1.5 ML 20 DCI 70  4213 1805 1829 1130 1731 1251 1731 1218
V115
KANGOO 1.5 ML 19 DCI 85+  4597 1810 1829 1130 1731 1251 2115 1218   2155
V115
KANGOO 1.5 LL 21 DCI 85 MAXI + 4597 1810 1829 1130 1731 1251 2115 1218   2155
V115
TRAFIC 2.0 LL 29 DCI 115 5182 1868 1904 1335 1390 1387 2800 1268 5.9 2900 1236
V220
TRAFIC 2.0 SL 29 DCI 115 4782 1868 1904 1335 1390 1387 2400 1268 5 2700 1247
V220
TRAFIC 2.0 SL 27 DCI 115 4782 1868 1904 1335 1390 1387 2400 1268 5 2700 1092
V220
MASTER 2.3 LM 35 DCI 125 6198 2496 2470 1820 1750 1780 3733 1380 13 3500 1530
V323
VAUXHALL ASTRAVAN 1.9 CDTI 16V SPORTIVE 4515 1500 1753 815 1050 900 1780 1380 ? 1960 650
V119
VIVARO 2.0 CDTI 115ps LWB 2.9T 5182 1960 1904 1320 1663 1387 2815 1268 5.9 2940 1214
V220
FIAT DOBC 1.3 MULTIJET 16V 4253 1831 1722 1305 1470 1305 1680 1230 3.2   730
V113
DOBC 1.6 MULTIJET 16V SX
V116
PEUGEOT PARTNER 1.6 HDI 90ps 850 S L1 4137 1796 1724 1246 1600 1305 1700 1200 3   600
V116
NISSAN NMAX 1.5 DCI SE 4400 1860 1695 1228 1500 1358 2040 1220   2000
V115
NMAX 2.3 DCI 125HP SE L3H2 3500
NV40
VW CADDY 1.6 TDI 75ps C20 4406 1823 1794 1129 1181 1244 1781 1172 3.2 2175 700
V116
CADDY 1.6 TDI 102ps C20 4406 1833 1794 1129 1181 1244 1781 1172 3.2 2175 697
V116
CADDY 1.6 TDI 102ps  4406 1833 1794 1129 1181 1244 1781 1172 3.2 2184 700
V116 BLUEMOTION C20
CADDY 1.6 TDI 102ps C20+ 4406 1833 1794 1129 1181 1244 1781 1172 3.2 2247 766
V116
CADDY 1.6 TDI 102ps MAXI C20 4876 1836 1794 1132 1181 1262 2250 1172 4.2 2310 750
V116
TRANSPORTER 2.0 TDI 84ps T26 SWB 4892 1990 1904 1424 1244 1410 2353 1244 5.8 2600 749
V220
